The fc-oogmsh Matlab toolbox make it possible to generate mesh files from .geo file by using gmsh. It’s also possible with the ooGmsh class to read the mesh file and to store its contains in more user-friendly form. This toolbox must be regarded as a very simple interface between gmsh files and Matlab. So you are free to create any data structure or object you want from an ooGmsh object.

  Requirements

This toolbox needs

• gmsh, a three-dimensional finite element mesh generator with built-in pre- and post-processing facilities, to be installed.
• Matlab (>= 2015b)

  Current development release

Version	date	archives	install	pdf
0.0.17	December 13, 2017	(33 Ko) (59 Ko) (28 Ko)	(2 Ko)	(357 Ko)

This toolbox was tested under

  Installation automatic, all in one (recommanded)

For this method, one just have to get/download the install file (2 Ko) mfc_oogmsh_install.m Thereafter, one run it under Matlab. This command download, extract and configure the fc-oogmsh toolbox and the required fc-tools toolbox in the current directory.

By default, the gmsh binary is supposed to be located in

• <USERDIR>/bin/gmsh under linux,
• <USERDIR>/GMSH/Gmsh.app/Contents/MacOS/gmsh under Mac OS X,
• <USERDIR>/Softwares/GMSH/gmsh.exe

To specify an other location one can do

where <GMSH> is the gmsh binary with path. It’s also possible, after installation, to change the gmsh binary by using the Matlab command

For example, to install this toolbox in ~/Matlab/toolboxes directory, one have to copy the file mfc_oogmsh_install.m in the ~/Matlab/toolboxes directory. Then in a Matlab terminal run commands :

There is the output of the mfc_oogmsh_install command on a Linux computer :

The complete toolbox (i.e. with all needed toolboxes) is stored in the directory ~/Matlab/toolboxes/fc-oogmsh-full and, for each Matlab session, one have to set the toolbox by :

For uninstalling, one just have to delete the directory :

  Version history

• 0.0.17 (December 13, 2017) : use of fc-tools toolbox version 0.0.19
• 0.0.16 (November 22, 2017) : modify sample in demo !.
• 0.0.14 (February 5, 2017) : first version for Linux, Windows and Mac OS X.

  Old development release

Version	date	archives	install	pdf
0.0.16	November 22, 2017	(32 Ko) (58 Ko) (27 Ko)	(2 Ko)	(355 Ko)
0.0.15	October 31, 2017	(32 Ko) (58 Ko) (27 Ko)	(2 Ko)	(340 Ko)
0.0.14	February 5, 2017	(30 Ko) (49 Ko) (25 Ko)	(2 Ko)	(366 Ko)
0.0.13	February 1, 2017	(30 Ko) (49 Ko) (25 Ko)	(2 Ko)	(350 Ko)
0.0.12	December 27, 2016	(29 Ko) (48 Ko) (25 Ko)	(2 Ko)	(351 Ko)
0.0.11	December 23, 2016	(29 Ko) (48 Ko) (25 Ko)	(2 Ko)	(350 Ko)
0.0.10	December 20, 2016	(29 Ko) (48 Ko) (24 Ko)	(2 Ko)
