Matlab / Numerical / fc-amat toolbox

Some demos

Matlab / Numerical / fc-amat/ Current development release

Auto. Inst.

Manu. Inst.

Matlab / Numerical / fc-amat/ Version history

Matlab / Numerical / fc-amat/ Old development releases

pict pict

The

Matlab toolbox allows to eﬃciently extand some linear algebra operations on array of matrices (with same size) as matrix product, determinant, factorization, solving, ...

Matlab / Numerical / fc-amat/ demos

description	code/results	description	code/results

simple example 01		simple example 02
simple example 03		simple example 04
benchmark : solving linear systems		Linear combination

Matlab / Numerical / fc-amat/ Current development release

Version

date

full archives

install

User guide

0.1.2

February 17, 2020

(135 Ko)

(270 Ko)

(78 Ko)

(3 Ko)

(1253 Ko)

This toolbox was tested on various OS with Matlab releases :



Operating system	2017a	2017b	2018a	2018b	2019a

CentOS 7.7.1908	✓	✓	✓	✓	✓

Debian 9.11	✓	✓	✓	✓	✓

Fedora 29	✓	✓	✓	✓	✓

OpenSUSE Leap 15.0	✓	✓	✓	✓	✓

Ubuntu 18.04.3 LTS	✓	✓	✓	✓	✓


MacOS High Sierra 10.13.6	✓	✓	✓	✓	✓

MacOS Mojave 10.14.4	✓	✓	✓	✓	✓

MacOS Catalina 10.15.2	✓	✓	✓	✓	✓


Windows 10 (1909)	✓	✓	✓	✓	✓

It is not compatible with Matlab releases prior to R2015b.

Matlab / Numerical / fc-amat/ Automatic installation, all in one (recommended)

For this method, one just has to get/download the install ﬁle mfc_amat_install.m Thereafter, one runs it under Matlab. This script downloads, extracts and conﬁgures the fc-amat and all the required toolboxes in the current directory.

For example, to install this toolbox in ~/Matlab/toolboxes directory, one has to copy the ﬁle mfc_amat_install.m in the ~/Matlab/toolboxes directory by using previous link. For example, in a Linux terminal, we can do :

Linux Console

cd ~/Matlab/toolboxes
HTTP=https://www.math.univ-paris13.fr/~cuvelier/software/codes/Matlab
wget $HTTP/fc-amat/0.1.2/mfc_amat_install.m

Then in a Matlab terminal run the following commands

Matlab Console

>> cd ~/Matlab/toolboxes
>> mfc_amat_install()

The optional ’dir’ option can be used to specify installation directory :

mfc_amat_install(’dir’,dirname)

where dirname is the installation directory (string).
There is the output of the mfc_amat_install() command on a Linux computer :

Matlab Ouput

Parts of the <fc-amat> Matlab toolbox.
Copyright (C) 2018-2020 F. Cuvelier

1- Downloading and extracting the toolboxes
2- Setting the <fc-amat> toolbox
Write in /home/cuvelier/tmp/fc-amat-full/fc_amat-0.1.2/configure_loc.m ...
3- Using toolboxes :
   ->             fc-tools : 0.0.30
   ->             fc-bench : 0.1.2
with              fc-amat : 0.1.2
*** Using instructions
   To use the <fc-amat> toolbox:
   addpath(’/home/cuvelier/tmp/fc-amat-full/fc_amat-0.1.2’)
   fc_amat.init()

   See /home/cuvelier/tmp/mfc_amat_set.m

The complete toolbox (i.e. with all the other needed toolboxes) is stored in the directory ~/Matlab/toolboxes/fc-amat-full and, for each Matlab session, one have to set the toolbox by :

Matlab Console

>> addpath(’~/Matlab/toolboxes/fc-amat-full/fc-amat-0.1.2’)
>> fc_amat.init()

If it’s the ﬁrst time the fc_amat.init() function is used, then its output is

Matlab Ouput

Try to use default parameters!
Use fc_tools.configure to configure.
Write in ~/Matlab/toolboxes/fc-amat-full/fc_tools-0.0.30/configure_loc.m ...
Try to use default parameters!
Use fc_bench.configure to configure.
Write in ~/Matlab/toolboxes/fc-amat-full/fc_bench-0.1.2/configure_loc.m ...
Using fc_amat[0.1.2] with fc_tools[0.0.30], fc_bench[0.1.2].

Otherwise, the output of the fc_amat.init() function is

Matlab Ouput

Using fc_amat[0.1.2] with fc_tools[0.0.30], fc_bench[0.1.2].

For uninstalling, one just has to delete directory

~/Matlab/toolboxes/fc-amat-full

Matlab / Numerical / fc-amat/ Manual installation

Download one of the full archives (see web page) which contains all the needed toolboxes (fc-amat, fc-tools and fc-bench).
Extract the archive in a folder.
Set Matlab path by adding path of the needed toolboxes.

For example under Linux, to install this toolbox in ~/Matlab/toolboxes directory, one can download fc-amat-0.1.2-full.tar.gz and extract it in the ~/Matlab/toolboxes directory :

Linux Console

HTTP=https://www.math.univ-paris13.fr/~cuvelier/software/codes/Matlab
wget $HTTP/fc-amat/0.1.2/fc-amat-0.1.2-full.tar.gz
tar zxf fc-amat-0.1.2-full.tar.gz -C ~/Matlab/toolboxes

For each Matlab session, one has to set the toolbox by adding path of all toolboxes :

Matlab Console

>> addpath(’~/Matlab/toolboxes/fc-amat-0.1.2/fc_amat-0.1.2’)
>> addpath(’~/Matlab/toolboxes/fc-amat-0.1.2/fc_tools-0.0.30’)
>> addpath(’~/Matlab/toolboxes/fc-amat-0.1.2/fc_bench-0.1.2’)

Matlab / Numerical / fc-amat/ Version history

0.1.1 (January 2, 2020) : using fc-bench package version 0.1.1.
0.0.3 (March 9, 2019) : Modifying installation and conﬁguration ﬁles.
0.0.2 (September 17, 2018) : ﬁrst online version.

Matlab / Numerical / fc-amat/ Old development releases

Version

date

full archives

install

User guide

0.1.1

January 2, 2020

(129 Ko)

(259 Ko)

(74 Ko)

(3 Ko)

(1224 Ko)

0.0.3

March 9, 2018

(117 Ko)

(245 Ko)

(67 Ko)

(3 Ko)

(1232 Ko)

0.0.2

September 17, 2018

(113 Ko)

(225 Ko)

(66 Ko)

(3 Ko)

(1239 Ko)
